701Software SQL

701SERVER/701CLIENT SQL

File-Based & Data-Based Supported

A powerful Software for SCADA Control, Access Control, Time & Attendance, Payroll, Elevator Control, Car Park Control, Projects Management and Operators Authority Level Control. SOYAL 701SQL software support both File-Based and Data-Based system enabling customers select the system format per their needs.

◎ File-Based & Data-Based Supported
◎ Strong R&D capability for customized design
◎ Distributed Multiplex Hardware Management
◎ Multi-Function
◎ SCADA control
◎ Unicode supported
◎ Sending message,QR code by email
◎ Cross-System Software
◎ Capturing real time picture
◎ Effortless learning
◎ The Long-Term Service Software

701ServerSQL 10V2 Features

In the convenience for access control and time attendance management, SOYAL provides powerful software 701 ServerSQL & 701 ClientSQL,

which enhance efficiency significantly with user-friendly graphical interface while operating.

701ServerSQL acts as a bridge to coordinate the communication between the Host PC and access controllers,

as well as allows users to set parameters of access controller in different locations just through the Host PC at once.

Free to choose Database mode or File System mode

User can choose Database mode or File System mode according to needs and requirement. Built-in the same operation user interface for both modes
provides seamless upgrade from File System to Database easy and can be done without relearning.
- File System: Easy to set up and maintain, suitable for small to medium scale system
- Database System: Suitable for complex exchange data and transaction, centralized system, and medium to large scale system that required higher security.

701SERVER TCP-LINK & 701 CLIENT TCP-LINK

When enabling Database Mode, 701Server set as Server mode can support multiple remote 701Client connections at the same time, provides
centralized and unified system management that linked headquarter to branch office across the world. Through local or remote 701Client, you can edit
data, obtain real time status, and generate reports synchronically.

Specification

System Requirements

Operating System	Win7/ Win10, Windows Server 2012/2016/2018, hyper V
Processor Server	Intel® Pentium® and above
Installed Memory (RAM)	min. 8GB
Hard Disk	80GB of free space
Transmission interface	Built-in 10/100M RJ-45 networking and USB transmission interface

701ClientSQL 10V2 Features

Furthermore, all the event logs can be analyzed through 701ClientSQL to automatically generate daily or monthly time and attendance report of each individual. Besides,

701ClientSQL is also capable of payroll control, and setting the door group, time zone, user access level, etc.

With state of the art software development capability, Soyal customized solution on Campus Security Protection and others. Welcome to contact Soyal for customized software solution

* All of the report and user data can be exported into .txt/.csv file for HR, Accountant, or transfer to other software

SCADA

Remote monitoring and management control over SOYAL access controller, reader, and IO devices via mapping and graphical control icon to have a
quick glance over all area in the system.

Specification

System Requirements

Operating System	Win7/Win 10
Processor Server	Intel® Pentium® and above
Installed Memory (RAM)	min. 8GB
Hard Disk	80GB of free space
Transmission interface	Built-in 10/100M RJ-45 networking and USB transmission interface

Software Functions

Features	◾User operation interface included user access level, transaction record, HR operation, user card data management, and report generator ◾Must connect to 701ServerSQL ◾Target users: Security guard and human resource personnel
Access right	Login password. Operators Authority Level Control, Automatically record operation log
User Card Data setting	Guard, Invalid, Valide with access mode: Card only, Card+PIN, PIN only, Finger only, QR Code only, QR Code+PIN, expiration
Access Control System	Area Setting / Door Group Setting / Time Zone Setting / Holiday Setting / Duty Setting / User Card Setting / Card ID Registration / User Card Copy / Set User Access to specified Doors and Time Zone
Salary Edit	Can set up User Card and Salary at same time efficiency.
Preference setting	View Option of Report/History
QR Code	Generate QR Code and saved to user card data
Sending email	Email Notification for QR Code, Fire Event, Alarm Event, Student's Absent Event
Monitoring Reader Status	check the current controller status, and perform the actions such as open door directly via PC or arm/disarm the designated controller.
Export/Import	Import/Export User Data, Setting Paramaters and Multiple messages in .txt or .csv
SCADA mapping	Remote control, set up abnormal events indicator, enable arming and alarm output
Generate Report	Daily Transaction Log / Multiday Transaction Log / Daily Duty Report / Monthly Duty Report / Monthly Report / Multiday and Summary Time Attendance Report / Labor and Health Insurance Report
More Functions	Graphic Animation control function, AR-837-E supports 64 units mailbox management system, Multi-car share multi-space parking lot management solution, support dual IP Camera to auto capture user access, crowd anagement control display user in area

Features	◾Actual connection and communication to hardware, hardware management and setting ◾Target users: System installation & maintenance personnel and network & information management personnel
Installation Requirement	PC Minimum Requirements: 32bits CPU, 1.0GHz Speed, 521MB RAM,5GB HD Converter: Ethernet to RS-485 AR-727CM / USB to RS-485 AR-321CM Supported Operating System: Win7/Win 10/2012/2016/2018 / hyper V
Structure	-File Based: personal computer/work station/Server all supported -Data Based: distributed Multiplex Hardware Management Architecture
Capacity	Connectivity up to 4000 doors Setting Max. user card capacity 1024/3000/16000/65000
Access right	Login password Operators Authority Level Control Automatically record operation log
Multi-Door Controller setting	Anti-passback Auto open time zone Arming mode Active Release all doors Auto Reset Anti-pass Alarm when reader offline Door Number Duress Code Time-Scheduled Output setting for door relay & alarm relay in industry automation door bell for on/off duty Parking Lot space monitoring upload/download fingerprint data Master code to enter programming mode Force Open Alarm output Auto Re-lock (anti-tracking tailgate)
IP-Based controller setting	Force Alarm , Free Zone , read/write fingerprint data lift control
Setting Client computer	Setting Client computer to share the resources of Server computer which connect with controller.
Setting attendance report relevant information	Time attendance base on Work Time "First and Last Records" Or "Duty Function Key", Maximum User On System, Duty Start Time, Update clock, Backup Message File, Execute another program while startup like 701Client
